| Brand/make | SEKISUI SPECIALTY CHEMICALS CO., LTD. (JAPAN). |
|---|---|
| Material | CPVC (Chlorinated PVC) | Cell Classification: ASTM D-1784 (23447). |
| Standard | ANSI / ASTM | Pipe: ASTM F-441 | Fittings: ASTM F-439 / F-437. |
| Schedule | Schedule 80 (Sch80) |
| Size | 1/2" to 16" Diameter |
| Connection Types | Socket (S x S) | Threaded (FT x FT) | Socket x Threaded (S x FT) |
| Pipe Fitting's type | Coupling, 90 Elbow, 45 Elbow, Tee, Male Adapter, Female Adapter, Cap, Union, Flange (One-piece, Van Stone, Blind), Reducers, Bushings. |
| NSF Certification | NSF International Standard 14 & 61 (Excluding CPVC Pipe 20A). |
| Temperature Rating | Higher than PVC - suitable for hot chemical services up to ~93 deg C |
| Color | Light Gray / Cream. |
| Commercial Class | Type IV, Grade 1, CPVC 4120. |
| UV Resistant Option | ESLON UVS-VP - Outer layer highly weatherized plastic + inner PVC; no maintenance coating needed. |
| Application | High-temperature chemical process, Pulp & Paper, Electroplating, Semiconductor, Boiler Feed Water, Aquarium. |
